Model 1 Square Tube Die Sets
Square Tube Die Sets
One main die and follow bar required and priced separately. Tube clamp/pin included. Main die wrap 120 degrees, min. wall 1.6mm, max. wall 2.5mm.
Main die radius from the die centre to the (die face) side of the square tube.
Die Sets for:
Important General Information
Please note tube and pipe are dimensioned differently and therefore require different die sets.
Tubing is sized according to it's outside diameter (OD) and pipe is sized by it's nominal bore (NB) however the outside diameter must be known for correct die application.
Not all dies are suitable for bending aluminium or stainless steel, however all dies will bend chrome moly or mild steel. To determine material suitability, outside dimension and wall thickness, please refer to specifications for each size.
The Centre Line Radius is measured from the centre of the die to the centre of the tubing (tube, pipe).
Minimal wall thicknesses are a guide only.
Please call to confirm availability or to order: firstname.lastname@example.org
Tel 02 4677 1212. Prices subject to change without notice.
- Suitable for Model 1 Tube Bender
